PowerLine Magnetic Sheave Alignment Laser

MFR#: 40-6200
TIGER#: TS42369
Original price List Price: $1,655.30
You Save: $471.75 -28%
Original price $1,655.30 - Original price $1,655.30
Original price List Price: $1,655.30
Current price $1,183.55
$1,183.55 - $1,183.55
Current price $1,183.55
PowerLine Magnetic Sheave Alignment Laser
PowerLine Magnetic Sheave Alignment Laser - $1,183.55
$1,183.55
*Must Purchase 1 for PowerLine Magnetic Sheave Alignment Laser

The cart will thereforce automatically set Qty to 1 when you order this product

Ships Out Within: 7 - 10 Business Days Shipping Date By: 7/4/2024

One of our Sales Experts will be in touch!

  • Choice of Red or Green beam
  • ±1/16" at 10 ft. accuracy
  • Range up to 100 ft. (30m)
  • Decrease vibration on any Pulley/Sheave System
  • Compact size - easy to use on small diameter sheaves
  • Nickel-plated rare earth magnets
  • Beam spread of 60" at a distance of 3ft.

The Johnson Level PowerLine Magnetic Sheave Alignment is a tool that allows aligning the surfaces like those on pulleys and table surfaces very accurately using a tightly controlled beam of light. It decreases vibration on any pulley/sheave system. With its compact size, a precisely machined aluminum bar that houses the special laser system it is easy to use on small diameter sheaves.

This laser projects a flat, wedge-shaped beam that spreads to about 60 inches at a distance of three feet. It has an accuracy of ±1/16-inch at 10 feet and a range of up to 100 feet. The bar and targets are equipped with powerful nickel-plated rare earth magnets that hold them fast to the surfaces being measured. The flat surface has a Retro-Reflective film applied that enhances the visibility of the laser beam.

Ideal for use in indoor applications such as aligning belts, sheaves, sprockets, gear trains, rollers platforms, conveyors and other plant equipment. This Johnson Level Magnetic Sheave Alignment includes three precision machined magnetic targets, two "AAA" alkaline batteries, instructions manual with warranty card and hard-shell carrying case. It also comes with a 1-year warranty.

Configuration Options

The Johnson Level PowerLine Magnetic Sheave Alignment is available in different beam colors. Select your preference from the drop-down menu above.

  • 40-6200: Red Beam
  • 40-6210: Green Beam
  • Choice of Red or Green beam
  • ±1/16" at 10 ft. accuracy
  • Range up to 100 ft. (30m)
  • Decrease vibration on any Pulley/Sheave System
  • Compact size - easy to use on small diameter sheaves
  • Nickel-plated rare earth magnets
  • Beam spread of 60" at a distance of 3ft.

What’s in the Box

  • Johnson PowerLine Level Magnetic Sheave Alignment
  • 2 "AAA" alkaline batteries
  • User manual
  • Hard-shell carrying case
  • 1-year with warranty card

Available Package Options

Beam Color: Red or Green

Tiger Supplies offers a 30-day return policy from date of shipment for this product, subject to return shipping charges. The product must be in new condition and in its original packaging. We take the responsibility to make sure this product arrives in a brand new working condition. Should your item arrive damaged, we will take full responsibility and replace the product at no cost to you.

For complete details of our return policy and process, please refer to our general return policy page.

Battery/Power
Operating Time
Approximately 10 hours continuous use
Power Source
2 "AAA" alkaline batteries (included)
General
Dimensions
1.75" x 6.75" x 0.625" (144x171x15mm)
Laser Class
Class Il
Laser Type
532nm (Green), 635nm+/-10nm (Red)
Warranty
1-year warranty
Weight
14 oz. (0.39 kg)
Measuring Capabilities
Working Range
+/-1/16"/10ft. (+/-1.5mm/3m)
