GeoMax Zoom95 Robotic Total Station (w/o 360° prism)

by Geomax

MFR#: 918648

USD $19,800^.00 - USD $26,000^.00

List Price: USD

USD $24,600^.00

USD $19,800^.00 - USD $26,000^.00

USD $24,600^.00

Store Pickup: List of available stores available on the Checkout page.

GeoMax Zoom95 Robotic Total Station (w/o 360° prism) - USD $19,800^.00

USD $19,800^.00

*Must Purchase 1 for GeoMax Zoom95 Robotic Total Station (w/o 360° prism)

The cart will thereforce automatically set Qty to 1 when you order this product

Free Shipping (USA) Ships Out Within: 7 - 10 Business Days Shipping Date By: 6/6/2025

Documents

Item Brochure

Essential Add-Ons:

Universal Contractor's Tripod

Details

$54^.99

$95^.10

Aluminum Rod

Details

$38^.95

Fiberglass Rod

Details

$92^.25

Choose Your EDM Power: Select between accXess5 (500 m reflectorless) or accXess10 (1,000 m reflectorless) to match your range needs.
STReAM360 Tracking: Automatically search, lock, and aim at prisms using Scout, TRack, and AiM features.
Robotic Efficiency: One-person operation with fast motorization and fine aiming at distances up to 1,000 meters.
Modern Touch Interface: 5” WVGA color touchscreen (800x480) with LED backlight and full alphanumeric keyboard.
X-PAD Ultimate Integration: Work with CAD files, connect to X-PAD 365 cloud platform, and sync with Android or Windows controllers.
Flexible Data Storage: 2 GB internal memory, SD card slot, and USB support for smooth file transfer.
Reliable Field Performance: IP55 rated, -22°F to +122°F temperature range, 8-hour runtime, and removable Li-ion battery.
Laser Plummet: Red dot laser point with adjustable brightness, accurate to 1.5 mm at 1.5 m height.

The GeoMax Zoom95 robotic total station is designed for surveyors who demand speed, accuracy, and one-person operation. Unlike manual or motorized total stations, robotic models like the Zoom95 allow a single operator to control the instrument remotely - streamlining workflows and improving productivity in the field.

With angular accuracy options of 1", 2", 3", or 5", and a measurement range of up to 3,500 meters with a prism, the Zoom95 is built for demanding layout and surveying tasks. Reflectorless measurement options vary by model—accXess5 supports up to 500 meters, while accXess10 extends up to 1,000 meters—so users can choose the right configuration based on range requirements.

At the core of the system is the STReAM360 technology, which uses Scout to detect prisms quickly, TRack to maintain lock even during movement, and AiM to ensure precise aiming. The large 5-inch color touchscreen and full alphanumeric keyboard enable intuitive control, while X-PAD Ultimate field software ensures a seamless workflow with CAD support and cloud integration via X-PAD 365.

Built to withstand rugged field conditions, the Zoom95 has an IP55 rating, operates in temperatures from -22°F to +122°F, and delivers up to 8 hours of runtime on its removable Li-ion battery.

Robotic total station with one-person operation via controller
Choose between accXess5 (500m) or accXess10 (1,000m) for reflectorless EDM
3,500m prism range and up to 5" angular accuracy
STReAM360 technology: Scout, TRack, and AiM for fast and reliable targeting
5" color touchscreen (800x480) with LED backlight
X-PAD Ultimate software with CAD, cloud, and Android/Windows support
Quadruple-axis compensator ensures tilt correction and measurement stability
IP55-rated with 8-hour battery runtime
Operating system: Microsoft Windows EC 7.0
Compatible with X-PAD 365 for cloud-based data backup and collaboration

What’s in the Box

(1) Zoom75 Total Station
Shipping Case
Quick Guide

Tiger Supplies offers a 30-day return policy from date of shipment for this product, subject to a 20% restocking fee, in addition to the return shipping charges. The product must be in new condition and in its original packaging. We take the responsibility to make sure this product arrives in a brand new working condition. Should your item arrive damaged, we will take full responsibility and replace the product at no cost to you.

For complete details of our return policy and process, please refer to our general return policy page.
