GL1425C Dual Grade Laser with Bluetooth

MFR#: GL1425C
TIGER#: TS20967
Original price List Price: $2,990.00
You Save: $598.00 -20%
Original price $2,990.00 - Original price $2,990.00
Original price List Price: $2,990.00
Current price $2,392.00
$2,392.00 - $2,392.00
Current price $2,392.00
GL1425C Dual Grade Laser with Bluetooth
GL1425C Dual Grade Laser with Bluetooth - $2,392.00
$2,392.00
*Must Purchase 1 for GL1425C Dual Grade Laser with Bluetooth

The cart will thereforce automatically set Qty to 1 when you order this product

Free Shipping (USA) Ships Out Within: 2 - 4 Business Days Shipping Date By: 6/20/2024

One of our Sales Experts will be in touch!

Essential Add-Ons:
Aluminum Rod
Aluminum Rod
Details
$43.95
$44.95
Universal Contractor’s Tripod
Universal Contractor’s Tripod
Details
$75.99
$79.99
Topcon LS-B20 Machine Control Laser Receiver - 1063525-03
Topcon LS-B20 Machine Control Laser Receiver - 1063525-03
Details
$651.60
Fiberglass Rod
Fiberglass Rod
Details
$76.95
  • Operating range: up to 2,600 feet (800 meters) diameter with a laser detector
  • Grade range: -10% to +15% in both the X and Y axes
  • Accuracy: ±1/16 inch per 100 feet (1.5 mm per 30 meters)
  • Self-leveling range: ±5 degrees
  • Rotation speed: 900 rpm
  • Laser diode: 10mW, 635nm red
  • Battery life: up to 35 hours of continuous use
  • IP rating: IP66, dustproof and water-resistant
  • Operating temperature range: -4°F to +122°F (-20°C to +50°C)

The Spectra GL1425C Dual Grade Laser is a rugged, precise, and accurate self-leveling grade laser designed for leveling, grading, and vertical alignment. Made to boost job site efficiency, the GL1425C can be controlled right from your smartphone via Bluetooth. It also comes with a remote controller. This grade laser can withstand 1-meter drops onto concrete, ensuring years of quality service.

Spectra GL1425C

ROBUST BLUETOOTH-ENABLED DUAL-GRADE LASER

Spectra GL1425C Working range

Working range:
2,600 ft.

Spectra GL1425C Accuracy

Accuracy:
±1/16 inch at 100 ft.

Spectra GL1425C Working range

Dual slope range:
±15%

Spectra GL1425C Working range

Rotation selection:
300, 600, or 900 RPM

Spectra GL1425C Working range

IP66 waterproof
and dustproof.























 WIRELESS CONTROL FOR UNINTERRUPTED WORKFLOW

Stay on top of your work wherever you are on the construction site with wireless control.

Control with your smart device via Bluetooth

  • Eliminates the cost of the remote control
  • Benefit from the large and familiar graphic interface of your phone or tablet for a much easier laser operation
  • Free Android and iOS app: Spectra Laser Control app

Control with the RC1402 remote controller

  • Working range of up to 330 feet
  • Backlit LDC screen
  • 130-hour battery life
  • IP66 rating for water and dust protection
  • Included in the package

HOW THE GL1425C ENSURES ACCURACY

The GL1425C has advanced features that not only ensure consistent accuracy but also fast-track setups and measurement times.

  • Height of Instrument or Shock Alert - Stops the laser from rotating when the laser moves or falls over to prevent erroneous readings.
  • Automatic Grade Matching - Matches the rise or fall of the ground between two unknown elevations and shows the value on the laser display, remote control, or app. This eliminates the need for complex, error-prone calculations.
  • PlaneLok - Stops the beam from drifting due to vibrations, changing temperature, and other factors to reduce measurement errors.

DO MORE WITH SPECTRA LASER RECEIVERS

The GL1425C Dual Grade Laser includes the HL760 Laser Receiver, a robust receiver for basic and advanced applications. It can also be paired with the CR700 Receiver (sold separately) for machine-guided applications.

HL760 Laser Receiver

  • Robust receiver for basic and advanced leveling and aligning applications
  • Digital readout of elevation saves significant time by removing the need to “on-grade” before measuring
  • IP67 dustproof, waterproof, and weatherproof
  • Battery life: 60+ hours

CR700 Laser Receiver

  • Machine-mounted receiver for small grading and excavating machines
  • Extremely bright LED lights
  • Includes a magnetic mount and grade rod clamp
  • IP67 dustproof, waterproof, and weatherproof
  • Battery life: 60+ hours

WHERE TO USE THE GL1425C DUAL GRADE LASER

  • Flatwork applications such as building pads, forms, and footers
  • Single-grade applications including trenching, sewer lines, and driveways
  • Dual-grade applications including drainage, sports fields, parking lots, and runways
  • Vertical alignment applications such as anchor bolt and form alignment

 With the Spectra GL1425C Dual Grade Laser, you can do more without sacrificing precision and accuracy.


No Cost 5-Year Warranty offers no repair charge for parts and labor of the laser.

Shock Proof ensures this construction laser withstands a three-foot drop onto concrete.

The included Radio Remote control is easier to use because it does not have to be aimed at the laser for it to work. This increases the flexibility of the laser for long-range setups while maintaining outstanding accuracy.

Grade Match enables contractors to measure an unknown grade value automatically between two elevation points.

Dual Axis PlaneLok keeps the laser beam fixed to a receiver in a set position, making it accurate and error-free.



CLICK “ADD TO CART” TO PLACE YOUR ORDER TODAY!

What’s in the Box

  • Spectra GL1425C Dual Grade Laser
  • RC1402 Radio Remote Control
  • HL760 Laser Receiver with Adapter C70
  • B10 NiMH Rechargeable Batteries & Charger
  • Carrying case
  • User manual
  • 5-year manufacturer’s warranty

Tiger Supplies offers a 30-day return policy from date of shipment for this product, subject to a 20% restocking fee, in addition to the return shipping charges. The product must be in new condition and in its original packaging. We take the responsibility to make sure this product arrives in a brand new working condition. Should your item arrive damaged, we will take full responsibility and replace the product at no cost to you.

For complete details of our return policy and process, please refer to our general return policy page.

Accuracy
Horizontal
±1/16" at 100 feet (1.5 mm per 30 m)
Applications
Concrete Forms, Footings and Foundations
Yes
Checking Building Square & Area
Yes
Checking Elevations of Sub-Base and Sub-Grade
Yes
Checking/Setting Elevations
Yes
Estimating Cut & Fill
Yes
Installation of Interior Fittings (cabinets, lighting, windows, countertops, etc.)
Yes
Installation/Leveling Ceiling Grids
Yes
Installation/Leveling Interior Walls
Yes
Locating Finished Floor Levels
Yes
Machine Control of Excavators, Graders, Dozers or Similar Equipment
Yes
Matching Existing Slope & Grade
Yes
Plumb Reference
Yes
Short-Range Leveling for Decks, Patios & Swimming Pools
Yes
Short-Run Vertical Alignment
Yes
Squaring and Layout of Partitions, Walls & Tile Floors
Yes
Transferring Points from Floor to Ceiling
Yes
Battery/Power
Battery Life Alert
Yes
Battery Life with Alkaline Batteries
Up to 40 hours
Battery Life with Rechargeable Battery Pack
Up to 35 hours
Power Source
Rechargeable NiMH or alkaline batteries
Extra Technology
Detector/Receiver
HL760
Remote Control
RC602N (Optional)
Features
Adjustable Rotating Speed
0 to 900 RPM
Automatic Shut-Off
Yes
Built-in Bubble Vial
Yes
Detecting Indicator
LCD indications and LED flashes
Display
Backlit, graphic LCD
Drop Damage Protection
Up to 3 feet drop onto concrete
Protection Class
IP67 dustproof & water immersible
Tripod Adapter (Center Screw Thread)
5/8 x 11
Functions
Automatic Leveling
Yes
Beam Operating Modes
Beam masking
Grade Operation
Automatic
Scanning Modes
Five preset sizes and variable adjustment
Slope Match
Yes
General
Remote Control Operating Distance
Up to 490 ft (150 m)
Warranty
5-year
Weight
6.8 lbs (3.1 kg)
Grade
Accuracy
±1/8” per 100 ft. (3.0 mm per 30 m)
Percentage
±25%
Type
Dual
Laser
Classification
Class 3A/3R
Color
Red
Direction
Horizontal and vertical
Visibility
Visible
Wavelength
650 nm
Range
Exterior
Up to 2,600 feet (792 m)
Remote
Up to 490 feet (150 m)
Self Leveling
±14 degrees
Temperature
Operating
-4 to 122 °F (-20 to 50 °C)
Storage
-4 to 158 °F (-20 to 70 °C)
