Topcon B40A-25 24x Automatic Level | 1009572-53
Sokkia1 reviewOriginal price List Price: $355.00You Save: $127.00Original price $355.00 - Original price $355.00Original price List Price: $355.00Current price $228.00$228.00 - $228.00Current price $228.00| /- Magnification: 24x
- Objective Aperture: 32 mm
- Resolving Power: 4"
- Minimum Focus: 0.2 m (from end of telescope)
- Field of View (at 100 m): 1°25′ (2.5 m)
- Image: Erect
- Reticle: Wedge cross line
- Stadia Ratio/Constant: 100 / 0
- Accuracy (1 km double run): ±2.0 mm
- Compensator: Pendulum with magnetic damping
- Setting Accuracy: 0.5"
- Working Range: ±15′
- Horizontal Circle: Diameter: 103 mm, Graduations: 1° / 1gon
- Water Resistance: IPX6 (High-pressure jet-proof)
- Operating Temperature: -4°F to +122°F (-20°C to +50°C)
Original price List Price: $355.00You Save: $127.00Original price $355.00 - Original price $355.00Original price List Price: $355.00Current price $228.00$228.00 - $228.00Current price $228.00| /
An Automatic Level is a self-leveling optical instrument designed for surveyors, builders, engineers, and other construction professionals. It is designed to precisely measure horizontal planes and angles at both long and short distances. With its built-in compensator, an auto level remains level and accurate, making it very easy to set up and use.
Automatic Level Applications
Compact and lightweight, auto levels improve accuracy when grading a roadway, setting the foundation for a new home, landscaping, fence building, and more. Most surveying levels can be used in dusty job site conditions, can withstand light rainfall, and even survive a fall into the water.
Choosing the Right Auto Level
Since there is a wide range of jobs that can benefit from the use of automatic levels, there are different specifications to choose from. Consider aspects like accuracy, magnification, and compensator range. Look at different options, including 360-degree horizontal circle, optical sight lens, focusing knobs, bubble level vials, and removable eyepieces for mounting a diagonal eyepiece prism, and a high-power lens for increased magnification.
Automatic levels are great for fence builders, foundation installers, deck builders, landscaping pros, home builders, roadwork workers, and more. Automatic levels require approximate leveling by hand; from there the automatic levels compensator takes over and levels itself precisely. Easier. Quicker. Greater accuracy.
Tiger Supplies is an authorized dealer for a wide range of Sokkia automatic levels. For the full setup package, you can choose from our auto level kits that include a grade rod and tripod. Shop now!
